• Measurements from 1 kΩ to 100 TΩ, with auto ranging • 0.5% measurement accuracy • Improved High-visibility blue LCD graphical display for menu programming and test results • Programmable test voltage from 1 to 1000 Vdc • Fully programmable measure cycle times • Automatic test lead zeroing to eliminate connection errors • Automatic open/short compensation eliminates connection errors • Direct reading of measured resistance or current • RS-232, Flash Drive for data storage in CSV format and uploading test setup conditions, and PLC Interfaces Standard, IEEE-488 Optional • IET 1865 Plus LabView Driver for IEEE-488.2 and RS-232
